AOD4130 Real Image AOD4130 real image1863
Same model may have multiple batches, images only for reference.
AOD4130 Real Image AOD4130 real image1863
AOD4130 Real Image AOD4130 real image1863
Same model may have multiple batches, images only for reference.

AOD4130

Part No AOD4130
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 30A TO252
Datasheet
AOD4130 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 6.5A (Ta), 30A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.8V @ 250μA
Max Gate Charge 34nC @ 10V
Max Input Capacitance 1900pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 52W (Tc)
Maximum Rds On at Id,Vgs 24 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252, (D-Pak)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 009796-AOD4130
Family Name AOD4130
Introduction Date April 05, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AOD4130 CAD Model

Description

AOD4130 Description

The AOD4130 is a robust power MOSFET offering high current capability and effective performance. It is suited for high-power and high-efficiency applications.

  • Applications: Electric vehicle powertrains, solar inverters, and industrial automation systems.
  • Features and Benefits: Equipped with a large current capacity, reduced switching losses, and enhanced thermal performance, ideal for intensive power applications.
  • Additional Details: Designed for high reliability and longevity, the AOD4130 aligns with stringent industry benchmarks.
