AON6284 Real Image AON6284 Real Image
Same model may have multiple batches, images only for reference.
AON6284 Real Image AON6284 Real Image
AON6284 Real Image AON6284 Real Image
Same model may have multiple batches, images only for reference.

AON6284

Part No AON6284
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 80V 78A 8-DFN
Datasheet
AON6284 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 80V
Continuous Drain Current at 25°C 24A (Ta), 78A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 3.3V @ 250μA
Max Gate Charge 40nC @ 10V
Max Input Capacitance 2162pF @ 40V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 7.4W (Ta), 78W (Tc)
Maximum Rds On at Id,Vgs 7.1 mOhm @ 20A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN (5x6)
Dimension 8-PowerSMD, Flat Leads
Win Source Part Number 1017040-AON6284
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AON6284 CAD Model

Description

The Alpha & Omega Semiconductor Inc. AON6284 is an N-Channel MOSFET.

  • Power Dissipation: 7.4W (Ta), 78W (Tc)
  • Drain-Source Breakdown Voltage: 80V
  • Continuous Drain Current: 24A (Ta), 78A (Tc)
  • Gate-Source Threshold Voltage: 3.3V @ 250μA
  • Maximum Gate Charge: 40nC @ 10V
  • Maximum Rds On: 7.1 mOhm @ 20A, 10V
  • Package: 8-DFN (5x6)
  • Applications: Discrete semiconductor products such as power supplies, motor controls, and DC-DC converters
