AZ2013-05R Amazing
Same model may have multiple batches, images only for reference.

AZ2013-05R

Part No AZ2013-05R
Manufacturer Amazing
Catalog TVS - Diodes
Description TVS DEVICE LOW SPEED 5-CH 3.3V
Datasheet
AZ2013-05R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Unidirectional Channels 5
Voltage - Reverse Standoff (Typ) 3.3V (Max)
Voltage - Breakdown (Min) 4.5V
Power Line Protection No
Applications General
Temperature Range - Operating -55°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case SOT-563, SOT-666
Supplier Device Package SOT-563
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 713599-AZ2013-05R
Ultra Librarian 3D Model Ultra Librarian AZ2013-05R CAD Model

Description

The 713599-AZ2013-05R is a Zener type transient voltage suppressor (TVS) diode designed for circuit protection.

  • Type: Zener
  • Channel: Unidirectional
  • Reverse Standoff Voltage: 3.3V (maximum)
  • Breakdown Voltage: 4.5V (minimum)
  • Package/Case Options: SOT-563, SOT-666
  • Temperature Range: -55°C to 85°C
  • Manufacturer: Amazing
