AZ3133-08F Amazing
Same model may have multiple batches, images only for reference.

AZ3133-08F

Part No AZ3133-08F
Manufacturer Amazing
Catalog TVS - Diodes
Description TVS SURGE PROTECTOR 4-CH 3.3V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Bidirectional Channels 8
Voltage - Reverse Standoff (Typ) 3.3V (Max)
Voltage - Breakdown (Min) 3.9V
Power Line Protection No
Applications Ethernet
Temperature Range - Operating -55°C ~ 125°C (TC)
Mounting Type Surface Mount
Package / Case 10-UDFN Exposed Pad
Supplier Device Package DFN3020P10E
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 818300-AZ3133-08F
Ultra Librarian 3D Model Ultra Librarian AZ3133-08F CAD Model

Description

The Amazing 818300-AZ3133-08F is a Zener type transient voltage suppressor (TVS) diode designed for circuit protection in Ethernet applications.

  • Voltage Reverse Standoff: 3.3V (maximum)
  • Voltage Breakdown: 3.9V (minimum)
  • Channel Count: 8 (bidirectional)
  • Package: 10-UDFN exposed pad
  • Temperature Range: -55°C to 125°C
  • Manufacturer: Amazing
  • Status: Active
