Analog Devices Inc. introduces the 111239-HMC567LC5, a state-of-the-art GaAs MMIC PHEMT Distributed Power Amplifier die that operates between 6 and 18 GHz. This versatile amplifier provides excellent dynamic range with a 3 dB noise figure and 15 dB of gain while requiring only 100 mA from a 5V supply.

Key Features

• Frequency Range: 6 - 18 GHz, making it suitable for a wide range of applications in the microwave spectrum.
• Gain: 15 dB gain ensures a robust signal amplification, crucial for maintaining signal integrity in complex systems.
• Noise Figure: A low noise figure of 3 dB, providing clear signal amplification with minimal added noise.
• Output Power: Delivers +23 dBm of saturated output power, ideal for high-power requirements.
• Power Supply: Operates on a 5V supply, drawing a modest 100 mA current, ensuring efficient power usage.
• Package: Comes in a compact 5x5 mm SMT package, the HMC567LC5, which is perfect for space-constrained applications.

Applications

The HMC567LC5 is designed for a variety of applications, including:

• Point-to-point and point-to-multipoint radios
• Test instrumentation
• Military & space
• Fiber optics
• Wideband communication systems

Product Quality and Support

Analog Devices Inc. is renowned for its high-quality products, and the HMC567LC5 is no exception. It is manufactured to meet the highest industry standards, ensuring reliability and performance. Technical support and detailed documentation are readily available, assisting customers in integrating this amplifier into their designs with ease.

Ordering Information

To purchase the HMC567LC5 or to obtain more information about pricing and availability, please contact Analog Devices Inc. or visit their official website.
