Analog Devices Inc. AD736AR True RMS-to-DC Converter

The AD736AR from Analog Devices Inc. is a high-precision, low-power, true RMS-to-DC converter that efficiently computes the true root-mean-square value of any complex waveform. It is particularly well-suited for applications that require an accurate RMS calculation for AC signals with a wide dynamic range. This integrated circuit offers a broad range of features that make it a versatile choice for a variety of industries, including test and measurement, audio processing, and industrial control systems.

Key Features:

• Wide Bandwidth: The AD736AR features a bandwidth that extends from DC to over 200 kHz, allowing it to accurately process signals from low frequencies up to those found in high-speed communication systems.
• Low Power Consumption: With its low power design, the AD736AR is ideal for portable and battery-powered applications, as it minimizes power usage without sacrificing performance.
• High Accuracy: It offers excellent accuracy over a wide temperature range, ensuring reliable performance in various operating conditions.
• Single or Dual Supply Operation: The device can be configured to operate from a single supply of +5V or from dual supplies of ±15V, providing flexibility in system design.
• Compact Package: Available in an 8-pin SOIC package, the AD736AR is designed for space-constrained applications, offering a high level of integration in a small footprint.

Applications:

• Audio equipment
• Signal processing
• Power supply management
• Energy management systems
• Industrial automation

The AD736AR is a robust RMS-to-DC converter that simplifies the design of an RMS measurement block in any electronics system. Its ability to accept low-level input signals and its low input bias current make it particularly useful in systems where signal integrity is paramount. Whether you are designing professional audio equipment, precision power measurement tools, or complex industrial control systems, the AD736AR from Analog Devices Inc. is a reliable choice that ensures accurate RMS readings for a wide range of applications.
