AD8044ARZ-14

Part No AD8044ARZ-14
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VFB 160MHZ RRO 14SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tube/Rail
Status Active
Amplifier Type Voltage Feedback
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 170 V/μs
-3db Bandwidth 150MHz
Current - Input Bias 2μA
Voltage - Input Offset 1.4mV
Operating Supply Current 11.5mA
Channel Output Current 30mA
Supply Voltage - Operating 3 V to 12 V, ±1.5 V to 6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 008324-AD8044ARZ-14
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian AD8044ARZ-14 CAD Model

Description

The AD8044ARZ-14 from Analog Devices Inc. is a high-performance, quad-channel voltage feedback amplifier that offers a blend of speed, precision, and versatility. Designed to operate at high speeds with a low power consumption, this amplifier is an ideal choice for a wide range of applications, including video electronics, test equipment, and communication systems.

Key Features

  • High Speed: With a 160 MHz bandwidth and a 250 V/µs slew rate, the AD8044ARZ-14 is capable of handling high-speed signals with ease.
  • Rail-to-Rail Output: The amplifier provides a rail-to-rail output swing, which ensures maximum dynamic range, especially beneficial when operating at low power supply voltages.
  • Low Power Consumption: Despite its high-speed capabilities, the device maintains a low power consumption, making it suitable for portable and battery-powered applications.
  • Quad Channel: With four independent amplifiers in one package, this device offers compact and efficient design possibilities for multi-channel applications.

Applications

  • Video and Broadcast Equipment
  • ADC/DAC Buffering
  • Active Filters and Amplifiers
  • Test and Measurement Systems
  • Communication Infrastructure

Technical Specifications

Parameter Value
Number of Channels 4
Supply Voltage ±2.7V to ±6V
Operating Temperature -40°C to +85°C
Package 14-SOIC
Mounting Type Surface Mount

The AD8044ARZ-14 is available in a 14-SOIC package, making it suitable for surface mount technology and easy integration into a variety of electronic assemblies. With its robust design and impressive electrical characteristics, this amplifier is a reliable and powerful solution for designers looking to enhance the performance of their high-speed signal processing systems.
