The AD8421BRZ-R7 is a high-performance instrumentation amplifier from Analog Devices Inc., designed to deliver precision, low noise, and high gain accuracy. This product is optimized for medical applications, industrial controls, and precision data systems where tight signal conditioning is required.

Key Features

• High Gain Accuracy: The AD8421BRZ-R7 offers a gain accuracy of ±0.25% for gains of 1 to 10,000, ensuring precise amplification of input signals.
• Low Noise: With a low input noise of 1 nV/√Hz at 1 kHz, this amplifier is ideal for applications requiring a clean signal amplification.
• Wide Bandwidth: It provides a 3-dB bandwidth of 10 MHz (G = 1), allowing it to handle a wide range of frequencies without distortion.
• High CMRR: The common-mode rejection ratio (CMRR) is greater than 80 dB for G = 1, which means the amplifier can effectively minimize noise and interference present in the common-mode signal.
• Low Power Consumption: The device operates with a quiescent current of 4 mA, making it suitable for battery-powered devices and portable applications.

Applications

• Medical instrumentation
• Industrial process controls
• Precision data acquisition systems
• Strain gages, transducer interfaces
• Thermocouple amplifiers

Product Specifications

The AD8421BRZ-R7 comes in a compact SOIC package with 8 leads, facilitating integration into a variety of circuit designs. It operates over a wide supply range of ±2.3 V to ±18 V, accommodating various power supply levels. Its robust design allows it to function effectively within an extended industrial temperature range of -40°C to +125°C.

Ordering Information

When ordering, the product is identified by the part number AD8421BRZ-R7, where "R7" denotes the packaging option (7" reel). This product is RoHS compliant and is available for purchase through Analog Devices Inc. and authorized distributors.
