The ADG1436YRUZ-REEL7 is a high-performance, dual-channel USB & multiplexing component from Analog Devices Inc., designed to deliver exceptional signal fidelity and connectivity in a broad range of applications. This precision analog switch is a part of their renowned switch and multiplexer product line, which is known for its reliability and versatility.

Key Features

• Low On-Resistance: The device features ultra-low on-resistance (Ron) typically around 3.5 Ω, which ensures minimal signal distortion and power loss when the switch is closed.
• Wide Voltage Range: It operates over a wide supply voltage range of ±5 V to ±16.5 V or a single supply of 10 V to 33 V, accommodating various application needs.
• Dual Independent Switches: The component consists of two independently controllable SPDT (Single Pole, Double Throw) switches, allowing for flexible signal routing.
• Fast Switching Times: It boasts fast switching times (tON and tOFF) in the nanosecond range, which is critical for high-speed digital and analog signal processing.
• Low Power Consumption: The ADG1436YRUZ-REEL7 is designed for low power consumption, making it suitable for power-sensitive applications.
• Extended Temperature Range: It is operational over an extended industrial temperature range of -40°C to +125°C, ensuring reliability in harsh environments.
• RoHS Compliant: The product is RoHS compliant, meeting environmental standards by avoiding hazardous substances.

Applications

This versatile switch is ideal for a variety of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Relay replacement
• Industrial control systems

Packaging and Quality

The ADG1436YRUZ-REEL7 is offered in a compact TSSOP-16 package and is supplied in a tape and reel format, which is suitable for automated assembly processes. Analog Devices Inc. ensures that each unit meets their high-quality standards, providing reliable performance for critical applications.
