Analog Devices Inc. ADG736BRMZ Dual SPDT Switch

The ADG736BRMZ is a high-performance, dual single-pole double-throw (SPDT) switch manufactured by Analog Devices Inc., a leader in high-performance semiconductors. This precision switch is designed to operate with a single supply voltage ranging from +1.8V to +5.5V, making it an ideal component for a wide variety of applications including data acquisition systems, communication systems, and portable devices.

Encased in a compact 10-lead MSOP (Mini Small Outline Package), the ADG736BRMZ offers a low on-resistance of typically 0.4 ohms, which ensures minimal signal distortion and power loss. Its on-resistance is matched between switches to within 0.2 ohms and is flat over the full analog signal range, providing excellent linearity and low signal attenuation.

The switch operates efficiently with a dual supply voltage ranging from ±2.5V to ±2.75V, and it features fast switching times with t_ON of 20 ns and t_OFF of 10 ns, thereby providing swift and responsive signal routing. The device also boasts a low power consumption, with a typical power supply current of just 0.01 µA, which is a crucial attribute for battery-powered devices where power efficiency is paramount.

One of the key benefits of the ADG736BRMZ is its high ESD (Electrostatic Discharge) protection level, which ensures the switch's robustness and longevity even in environments where ESD events are likely to occur. Additionally, the device is designed with break-before-make switching action, which prevents momentary shorting when switching channels.

For design flexibility, the ADG736BRMZ features a 3 V logic-compatible digital input, making it easy to interface with microcontrollers and other digital logic. This compatibility allows for seamless integration into digital systems without the need for additional level shifting or buffering components.

In summary, the ADG736BRMZ from Analog Devices Inc. is a versatile and high-performance dual SPDT switch that offers low on-resistance, matched switch characteristics, fast switching times, and low power consumption, making it a suitable choice for a multitude of applications that require reliable and efficient signal routing.
