Product Overview: ADG859YRYZ-REEL7

The ADG859YRYZ-REEL7, from Analog Devices Inc., is a high-performance CMOS analog switch that offers a multitude of features suitable for a wide range of applications. This switch is part of the ADG859 series, known for its low power consumption and high-speed operation. The device is packaged in a compact, lead-free SOT-23 package and is supplied on a 7" reel, making it ideal for automated assembly processes.

Key Features

• Single 2:1 Multiplexer/Demultiplexer Configuration: The ADG859YRYZ-REEL7 operates as a single 2:1 MUX/DEMUX, providing flexibility in signal routing for various circuit designs.
• Low Voltage Operation: This device can operate at a single supply voltage ranging from 1.8V to 5.5V, accommodating a variety of low-voltage applications and making it compatible with most modern low-voltage logic levels.
• Low On Resistance: The switch features an exceptionally low on resistance (typically 0.5 ohms), minimizing signal attenuation and ensuring high signal integrity.
• Fast Switching Times: It boasts fast switching times (t_ON and t_OFF) in the nanosecond range, contributing to improved performance in high-speed applications.
• High Current Carrying Capability: The ADG859YRYZ-REEL7 can handle continuous current up to 300mA, making it suitable for driving moderate loads directly.
• ESD Protection: The device provides enhanced electrostatic discharge (ESD) protection, ensuring reliability and longevity in harsh electrical environments.
• Lead-Free and RoHS Compliant: In alignment with environmental standards, the product is lead-free and RoHS compliant, reflecting Analog Devices Inc.'s commitment to environmentally responsible manufacturing.

Applications

The ADG859YRYZ-REEL7 is versatile and can be used in various applications including, but not limited to:

• Data acquisition systems
• Communication systems
• Audio and video signal routing
• Portable and battery-powered devices
• Sample and hold circuits
• Test equipment and instrumentation

With its robust design and reliable performance, the ADG859YRYZ-REEL7 from Analog Devices Inc. is an excellent choice for designers looking to integrate a high-quality analog switch into their electronic systems.
