ADM2484EBRWZ-REEL7 - Isolated RS-485/RS-422 Transceiver

The ADM2484EBRWZ-REEL7 is a robust isolated RS-485/RS-422 transceiver module from the renowned manufacturer Analog Devices Inc. This component is designed to provide reliable data communications on multipoint bus transmission lines, and it is an ideal choice for high-speed, bidirectional communication networks.

Key Features

• Integrated Isolation: The device features Analog Devices' iCoupler® technology, providing 2500 V RMS isolation for 60 seconds, which helps in protecting the system from surges and ground loops.
• High Data Rates: Capable of supporting data rates up to 16 Mbps, the ADM2484EBRWZ-REEL7 is suitable for high-speed applications that require fast data transmission.
• Thermal Shutdown Protection: With built-in thermal shutdown protection, the device ensures reliability and safety by preventing overheating.
• Low Power Operation: The transceiver operates with a low power supply, ranging from 3.0 V to 5.5 V, making it energy-efficient for various applications.
• Extended Temperature Range: The device is operational over an industrial temperature range of -40°C to +85°C, ensuring performance in harsh environments.
• Robust ESD Protection: It features high ESD protection levels on the bus pins, enhancing the durability of the system against electrostatic discharges.

Applications

The ADM2484EBRWZ-REEL7 is versatile and can be used in a wide array of applications, including but not limited to:

• Industrial field buses
• Data acquisition systems
• Building automation
• Factory automation
• Instrumentation

Reliability and Quality

Analog Devices Inc. ensures that the ADM2484EBRWZ-REEL7 meets the highest standards of quality and reliability. The device comes in a 16-lead, wide-body SOIC package and is available in tape and reel form, denoted by the -REEL7 suffix, facilitating efficient assembly during manufacturing processes.

With its combination of features, the ADM2484EBRWZ-REEL7 stands out as a superior solution for designers looking for an isolated RS-485/RS-422 transceiver that can deliver dependable performance in a variety of challenging environments.
