The ADM809TARTZ is a specialized microprocessor supervisory circuit produced by Analog Devices Inc., a leader in high-performance semiconductors. This compact device is designed to monitor power supplies in microprocessor systems, providing a high level of protection against low-voltage operation, which can lead to system malfunctions.

Key Features

• Precision Voltage Monitoring: The ADM809TARTZ accurately monitors 3.08V power supplies, ensuring that the microprocessor is reset to a known state during power-up, power-down, and brownout conditions.
• Low Power Consumption: This device is optimized for low power consumption, making it suitable for power-sensitive applications.
• Reset Output: The active-low reset output remains asserted for at least 140ms after Vcc has risen above the reset threshold level, providing ample time for the microprocessor to stabilize.
• Manual Reset Input: It features a manual reset input that enables a direct and immediate reset initiation.
• Compact SOT-23 Package: Housed in a small SOT-23 package, the ADM809TARTZ is ideal for space-constrained applications.

Applications

The ADM809TARTZ is versatile and can be used in various applications, including:

• Computers and Servers
• Embedded Systems
• Portable/Battery-Powered Equipment
• Industrial Controllers
• Intelligent Instruments

Quality and Reliability

Analog Devices Inc. is committed to the highest standards of quality and reliability, and the ADM809TARTZ is no exception. This device is manufactured using robust processes, ensuring consistent performance and longevity in the field.

Ordering Information

The ADM809TARTZ is available for order through authorized distributors of Analog Devices Inc. For detailed pricing and availability, please contact your local sales representative or visit the Analog Devices website.

Note: For comprehensive technical specifications, application notes, and support resources, please refer to the official Analog Devices Inc. documentation for the ADM809TARTZ.
