ADP172ACBZ-1.65-R7 Analog Devices Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ADP172ACBZ-1.65-R7

Part No ADP172ACBZ-1.65-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LIN 1.65V 300MA 4-WLCSP
Datasheet
ADP172ACBZ-1.65-R7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 3.6V
Voltage - Output (Min/Fixed) 1.65V
Voltage Dropout (Max) 0.1V @ 300mA
Current - Output 300mA
Current - Quiescent (Iq) 60 µA
Current - Supply (Max) 260 nA
PSRR 73dB ~ 47dB (1kHz ~ 100kHz)
Control Features Enable
Protection Features Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Case / Package 4-UFBGA, WLCSP
Supplier Device Package 4-WLCSP (0.95x1.03)
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1541260-ADP172ACBZ-1.65-R7
Ultra Librarian 3D Model Ultra Librarian ADP172ACBZ-1.65-R7 CAD Model

Description

N
