ADP3300ARTZ-3.3RL7

Part No ADP3300ARTZ-3.3RL7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 50MA SOT23-6
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 12V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.17V @ 50mA
Output Current 50mA
Operating Supply Current 300μA to 1.7mA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -55°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.08V @ 50mA
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 118356-ADP3300ARTZ-3.3RL7
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADP3300ARTZ-3.3RL7 CAD Model

Description

The ADP3300ARTZ-3.3RL7 is a high-performance, low-dropout linear regulator from Analog Devices Inc., designed to deliver a fixed output of 3.3 volts. This component is notable for its exceptional accuracy, low power consumption, and stability, making it an ideal choice for precision applications that require a consistent voltage supply.

Key Features

  • Output Voltage: Fixed 3.3V
  • High Accuracy: ±0.8% at room temperature, ±1.4% over temperature, line, and load conditions
  • Low Dropout Voltage: 180 mV (typical) at 50 mA load, which allows for efficient operation even when the input voltage is close to the output voltage
  • Low Quiescent Current: 120 μA (typical) in full operation, and 0.5 μA in shutdown mode, thereby preserving battery life in portable applications
  • Output Current: Capable of delivering up to 50 mA of output current
  • Stable with Low ESR Capacitors: Stable with ceramic and other types of capacitors as low as 1 μF
  • Package: Supplied in a compact SOT-23 package, marked as RL7

Applications

The ADP3300ARTZ-3.3RL7 is versatile and can be deployed in a wide range of applications, including:

  • Battery-powered devices
  • Portable and handheld equipment
  • Medical devices
  • Microprocessor/ microcontroller or FPGA power supplies
  • Reference voltage sources
  • Telecommunications equipment

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the ADP3300ARTZ-3.3RL7 is no exception. It is designed to meet the stringent requirements of even the most demanding applications, ensuring long-term stability and performance.

Ordering and Packaging

The ADP3300ARTZ-3.3RL7 comes in a reel, making it suitable for automated assembly processes and bulk purchasing. The product is available for order through Analog Devices Inc. or their authorized distributors.
