ADP3338AKCZ-2.5 Voltage Regulator by Analog Devices Inc.

The ADP3338AKCZ-2.5 is a high-precision, low-dropout voltage regulator designed and manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This particular model is part of the ADP3338 series, which is known for its high accuracy and reliability in a wide range of applications.

Key Features:

• Output Voltage: The regulator provides a fixed output voltage of 2.5V, which is suitable for powering sensitive analog and digital circuits that require a stable power supply.
• High Accuracy: With a tight output voltage tolerance, the ADP3338AKCZ-2.5 ensures precision and consistency, making it ideal for critical applications.
• Low Dropout Voltage: The device features a low dropout voltage, which allows it to maintain regulation even when the supply voltage is very close to the output voltage, enhancing the efficiency of the system.
• High Output Current: Capable of delivering up to 1A of output current, this regulator can handle a substantial load, making it versatile for a variety of uses.
• Thermal Overload Protection: The built-in thermal overload protection safeguards the device and the system from damage due to excessive heat.
• Short Circuit Protection: Additionally, the ADP3338AKCZ-2.5 includes short-circuit protection, enhancing its reliability and durability.
• Low Noise Performance: Engineered for low noise operation, this voltage regulator is suitable for noise-sensitive applications such as RF or precision measurement devices.
• Package: Housed in a compact 5-lead SOT-23 package, the ADP3338AKCZ-2.5 is designed for space-constrained applications.

Applications:

The ADP3338AKCZ-2.5 is versatile and can be used in a wide array of applications, including but not limited to:

• Portable and battery-powered devices
• Microprocessor and microcontroller systems
• Data acquisition systems
• Telecommunications equipment
• Medical devices

With its combination of features, the ADP3338AKCZ-2.5 from Analog Devices Inc. is a reliable choice for designers who require a stable and precise voltage regulator for their sensitive electronic circuits.
