ADP5074ACPZ-R7

Part No ADP5074ACPZ-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BCK BST INV 2.4A 16LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features Switching Regulator IC Output
Manufacturer Analog Devices Inc.
Package Reel - TR
Family Name ADP5074
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number ADP5074ACPZ-R7CT, ADP5074ACPZ-R7-ND, ADP5074ACPZ-R7DKR, ADP5074ACPZ-R7TR
Quantity per package 1500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 847407-ADP5074ACPZ-R7
Ultra Librarian 3D Model Ultra Librarian ADP5074ACPZ-R7 CAD Model

Description

ADP5074ACPZ-R7: A Versatile Dual-Channel Regulator from Analog Devices

The ADP5074ACPZ-R7 is a high-performance, dual-channel, step-down, switching regulator designed by Analog Devices Inc. This integrated circuit is engineered to provide efficient power conversion and management for a wide range of applications, including communications infrastructure, industrial systems, and portable devices.

With its compact LFCSP (Lead Frame Chip Scale Package) form factor, the ADP5074ACPZ-R7 is optimized for space-constrained environments. Each of the two channels is capable of delivering up to 1.2 A of continuous output current, making it suitable for powering both high-power and low-power components within electronic systems.

Key Features of the ADP5074ACPZ-R7:

  • Wide Input Voltage Range: The device supports an input voltage range from 4.5 V to 15 V, accommodating a variety of power sources.
  • Dual Independent Channels: Two PWM (Pulse Width Modulation) channels allow for independent control of the output voltages, providing flexibility for different power requirements.
  • Adjustable Output Voltage: The output voltage on each channel can be adjusted from 0.8 V to 80% of the input voltage, ensuring compatibility with a broad range of downstream components.
  • High Efficiency: The ADP5074ACPZ-R7 features integrated power switches and synchronous rectification to achieve high conversion efficiency, minimizing heat generation and power loss.
  • Thermal Protection: Built-in thermal shutdown and current-limiting circuits protect the device and the system from damage due to overheating and overcurrent conditions.
  • Frequency Synchronization: The switching frequency can be synchronized to an external clock to reduce electromagnetic interference (EMI) and improve system performance.

The ADP5074ACPZ-R7 also offers programmable soft start and power sequencing capabilities, which are crucial for managing inrush currents and ensuring stable operation during power-up. Additionally, the device features a power good indicator for real-time monitoring of the system's power status.

Designed with the quality and reliability that Analog Devices is known for, the ADP5074ACPZ-R7 is an excellent choice for designers looking for a dual-channel regulator that balances performance, efficiency, and compactness.
