ADR02ARZ-REEL7

Part No ADR02ARZ-REEL7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 5V 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 5V
Output Current 10mA
Tolerance ±0.1%
Temperature Coefficient 10ppm/°C
Noise - 0.1Hz to 10Hz 10μVp-p
Voltage - Input 7 V to 36 V
Operating Supply Current 1mA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 009188-ADR02ARZ-REEL7
Family Name ADR02
Introduction Date May 11, 2000
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADR02ARZ-REEL7 CAD Model

Description

Product Overview: ADR02ARZ-REEL7

The ADR02ARZ-REEL7 is a precision 5.0 V voltage reference component manufactured by Analog Devices Inc., an industry leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This product is part of Analog Devices' ADR02 series, which is renowned for its high accuracy, stability, and low power consumption.

Key Features

  • High Accuracy: The ADR02ARZ-REEL7 offers a tight initial accuracy of ±0.1%, ensuring precise voltage regulation for sensitive applications.
  • Low Temperature Coefficient: With a temperature coefficient of 10 ppm/°C maximum from -40°C to +125°C, the device maintains stable performance across a wide range of operating conditions.
  • Low Noise: This voltage reference boasts an exceptionally low noise performance of 1.0 µV p-p/V, which is critical for high-end instrumentation and data acquisition systems.
  • Long-Term Stability: It exhibits excellent long-term stability, making it reliable for extended periods of use in various applications.
  • Low Dropout Voltage: The ADR02ARZ-REEL7 operates with a low dropout voltage, enhancing its efficiency and making it suitable for battery-operated devices.
  • Wide Operating Range: The device can function over a broad supply voltage range from 7 V to 36 V, providing flexibility in design for multiple scenarios.
  • Output Current Capability: It can source or sink up to 10 mA of output current, accommodating a range of load conditions.

Applications

The ADR02ARZ-REEL7 is versatile and can be used in various high-performance applications, including:

  • Precision data systems
  • High-resolution converters
  • Battery-powered devices
  • Industrial control systems
  • Automotive electronics
  • Portable instrumentation

Packaging and Quality

This voltage reference comes in a compact SOIC-8 package, making it suitable for space-constrained applications. The ADR02ARZ-REEL7 is provided in tape and reel packaging, facilitating efficient assembly processes for high-volume production. Analog Devices Inc. ensures that this product meets stringent quality standards, providing reliability and performance that engineers and designers can trust for their critical projects.

With its combination of precision, stability, and low power consumption, the ADR02ARZ-REEL7 is an excellent choice for systems requiring a high-quality voltage reference solution.
