Product Overview: ADR03AKSZ-REEL7 by Analog Devices Inc.

The ADR03AKSZ-REEL7 is a precision 2.5V voltage reference device from Analog Devices Inc., designed to maintain high stability and accuracy over time and varying temperature conditions. This component is part of the ADR03 series and comes in a compact surface-mount package, making it suitable for automated assembly processes and space-constrained applications.

Key Features

• Output Voltage: Fixed 2.5V with high accuracy.
• Initial Accuracy: ±0.1% maximum for B Grade.
• Temperature Coefficient: 8 ppm/°C maximum over the full temperature range for B Grade, ensuring stable performance across diverse operating conditions.
• Long-Term Stability: Excellent long-term stability of 50 ppm typical after 1,000 hours.
• Low Noise: Offers low noise performance, making it ideal for precision applications.
• Supply Range: Wide supply range from 3.0V to 12.6V.
• Load Regulation: Superior load regulation characteristics.
• Package: Supplied in an 8-lead SOIC package on a 7-inch reel, denoted by the 'REEL7' suffix, facilitating efficient handling and placement during manufacturing.

Applications

The ADR03AKSZ-REEL7 is versatile enough to be used in a broad array of applications that require a stable reference voltage. These include:

• Precision data converters (ADCs and DACs)
• Portable instrumentation
• Battery-powered devices
• Industrial control systems
• Automotive electronics
• Medical and healthcare equipment

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality and reliability, and the ADR03AKSZ-REEL7 is no exception. This product is rigorously tested to meet stringent performance criteria, providing designers and engineers with a dependable voltage reference source that they can trust for their critical applications.

Overall, the ADR03AKSZ-REEL7 represents a blend of performance, versatility, and reliability, making it a prime choice for precision voltage reference needs across various industries and applications.
