ADUM7442CRQZ-RL7

Part No ADUM7442CRQZ-RL7
Manufacturer Analog Devices Inc.
Catalog Digital Isolators
Description DGTL ISO 1KV 4CH GEN PURP 16QSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Technology Magnetic Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Isolation Voltage 1000Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 50ns, 50ns
Pulse Width Distortion (Max) 5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 105°C
Case / Package 16-QSOP
Win Source Part Number 009541-ADUM7442CRQZ-RL7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ADUM7442CRQZ-RL7 CAD Model

Description

ADUM7442CRQZ-RL7 Digital Isolator by Analog Devices Inc.

The ADUM7442CRQZ-RL7 is a state-of-the-art digital isolator produced by Analog Devices Inc., renowned for its innovation in the field of high-performance analog, mixed-signal, and digital signal processing (DSP) integrated circuits (ICs). This product is designed to ensure reliable signal isolation in a variety of demanding applications, including industrial, medical, and automotive systems.

Key Features:

  • Quad-Channel Isolation: The ADUM7442CRQZ-RL7 offers four independent isolation channels, providing versatile integration options for multiple signal lines.
  • iCoupler® Technology: Utilizing Analog Devices' proprietary iCoupler® technology, the ADUM7442CRQZ-RL7 provides robust galvanic isolation between input and output, effectively protecting sensitive components from high voltage transients and ground potential differences.
  • High Data Rates: Capable of supporting data rates up to 1 Mbps, this digital isolator is suitable for applications requiring fast and reliable data transfer.
  • Low Power Consumption: Designed with power efficiency in mind, the ADUM7442CRQZ-RL7 minimizes power consumption, making it ideal for power-sensitive applications.
  • Wide Supply Voltage Range: It operates over a wide supply voltage range of 2.7 V to 5.5 V, providing flexibility in various system voltage levels.
  • High Operating Temperature Range: The device is rated for an industrial temperature range of -40°C to +125°C, ensuring reliable operation in extreme environments.
  • Enhanced System Safety: With its high isolation voltage rating, the ADUM7442CRQZ-RL7 enhances system safety by preventing electrical noise and voltage spikes from affecting the signal integrity.
  • Compact Package: The device is available in a compact, 16-lead QSOP package, making it suitable for space-constrained applications.

Applications:

  • Industrial automation and control systems
  • Medical equipment with stringent isolation requirements
  • Automotive systems where signal integrity and isolation are critical
  • Isolated sensor interfaces and data communication systems

The ADUM7442CRQZ-RL7 by Analog Devices Inc. is an exemplary solution for designers looking to enhance system reliability and integrity through superior isolation capabilities. Its robust design, combined with high-speed operation and low power consumption, makes it a versatile choice for a wide array of electronic applications.
