ADXL335BCPZ-RL7: 3-Axis Accelerometer by Analog Devices Inc.

The ADXL335BCPZ-RL7 is a small, thin, low-power, complete 3-axis accelerometer with signal-conditioned voltage outputs, all on a single monolithic IC. Manufactured by Analog Devices Inc., this high-performance product measures acceleration with a minimum full-scale range of ±3 g. It is designed to measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration.

With its small form factor, the ADXL335BCPZ-RL7 is ideal for mobile applications. It comes in a 4 mm × 4 mm × 1.45 mm LFCSP (Lead Frame Chip Scale Package), which is RoHS compliant and designed for space-sensitive devices. The accelerometer operates on a supply voltage ranging from 1.8 V to 3.6 V, making it suitable for battery-powered devices, and it has a typical current consumption of just 350 μA, which helps in power-sensitive applications.

The device features a 3-axis sensing ability that provides a direct, linear response to a wide range of motions. This analog output is ratiometric, meaning the output voltage scales with the supply voltage, and it can easily interface with any microcontroller with an analog-to-digital converter (ADC) or with an external ADC.

The ADXL335BCPZ-RL7 is temperature-stable and calibrated directly at the factory to ensure reliability and accuracy. Its performance is not only suitable for a variety of applications but also for highly demanding ones. Common applications include gaming and pointing devices, industrial instruments, personal navigation devices, and vehicle dynamics monitoring.

Analog Devices Inc. provides comprehensive technical support for the ADXL335BCPZ-RL7, including detailed datasheets, application notes, and reference designs to help developers integrate the accelerometer into their designs efficiently. The product is also supported by Analog Devices’ evaluation platforms, making prototyping and testing more convenient.

Whether you're developing a new innovative gadget or improving the functionality of existing devices, the ADXL335BCPZ-RL7 from Analog Devices Inc. offers the precision and durability needed for a wide range of acceleration sensing applications.
