Product Overview: LT3060EDC from Analog Devices Inc.

The LT3060EDC is a high-performance, low dropout linear regulator (LDO) brought to you by Analog Devices Inc., a leader in the field of high-performance analog technology. This regulator is designed to deliver continuous output currents up to 45mA with a drop-out voltage of only 300mV at full load, making it an excellent choice for battery-powered and low voltage applications.

Key Features

• Wide Input Voltage Range: Capable of operating with an input voltage range from 1.6V to 45V, the LT3060EDC provides users with a versatile solution for various applications.
• Adjustable Output: Users can set the output voltage from 0.6V to 44V via an external resistor divider, allowing for a high degree of flexibility in customizing the output to meet specific requirements.
• Low Noise: With only 30µVRMS (10Hz to 100kHz) of output noise, this LDO is ideal for noise-sensitive applications such as precision instrumentation and RF supply.
• Stable with Low ESR Ceramic Capacitors: The LT3060EDC remains stable with ceramic output capacitors, which are smaller, more reliable, and have lower equivalent series resistance (ESR) than other types of capacitors.
• Thermal Protection: The device includes internal thermal limit protection, which safeguards the regulator and the application from potential overheating.
• Current Limit Protection: It features current limiting to protect the device during overcurrent conditions.

Applications

The LT3060EDC is suitable for a wide array of applications, including but not limited to:

• Portable and battery-powered equipment
• Automotive power supplies
• Industrial supplies
• Avionics and military systems
• Medical devices

Package and Quality

Cased in a compact, thermally efficient 6-lead DFN package, the LT3060EDC ensures a minimal footprint on the PCB while providing excellent thermal performance. Analog Devices Inc. is committed to maintaining the highest standards of product quality and reliability, making the LT3060EDC a trusted choice for professionals seeking a dependable power management solution.
