Analog Devices Inc.

The HMC241ATCPZ-EP-R7 is a high-performance, non-reflective Single Pole Four Throw (SP4T) switch from Analog Devices Inc., designed to meet the rigorous requirements of space, defense, and industrial applications. This switch operates within the frequency range of DC to 3.5 GHz, offering a versatile solution for various RF and microwave signal routing needs.

Manufactured with a silicon-on-insulator (SOI) process, the HMC241ATCPZ-EP-R7 ensures exceptional isolation and linearity performance across its entire frequency range. The switch is characterized by its low insertion loss, typically 1.5 dB at 2 GHz, which makes it an excellent choice for maintaining signal integrity in complex RF systems.

The switch is housed in a compact 24-lead 4x4 mm ceramic package, making it suitable for space-constrained applications. Its EP (Enhanced Product) designation indicates that it has been subjected to additional testing and quality measures, ensuring reliability and performance consistency in demanding environments. The -R7 suffix denotes the packaging option, which is tape and reel, facilitating automated assembly processes.

Key features of the HMC241ATCPZ-EP-R7 include:

• Frequency Range: DC to 3.5 GHz
• Insertion Loss: 1.5 dB typical at 2 GHz
• Isolation: 45 dB typical at 2 GHz
• IIP3: +55 dBm typical
• Switching Speed: 6 ns typical
• Supply Voltage: +3V to +5V
• Control Voltage: 0/+5V

The HMC241ATCPZ-EP-R7 switch is equipped with an on-chip binary decoder, which reduces the number of required GPIO lines for control, simplifying the design and saving valuable board space. Its robust construction and proven reliability make it an ideal choice for applications such as phased array radars, electronic warfare systems, satellite communications, and test instrumentation where performance and durability are paramount.

Analog Devices Inc. provides detailed technical documentation, including datasheets, application notes, and design resources, to support the integration and use of the HMC241ATCPZ-EP-R7 in your projects. With its combination of performance, reliability, and compact form factor, this switch represents a superior choice for designers looking to optimize their RF signal routing capabilities.
