LT3045EMSE#TRPBF

Part No LT3045EMSE#TRPBF
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LIN POS PROG 500MA 12MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Analog Devices Inc.
Package Tape & Reel
Product Status Active
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 20V
Voltage - Output (Min/Fixed) 0V
Voltage - Output (Max) 15V
Voltage Dropout (Max) 0.45V @ 500mA
Current - Output 500mA
Current - Quiescent (Iq) 20 µA
Current - Supply (Max) 25 mA
PSRR 117dB ~ 53dB (120Hz ~ 10MHz)
Control Features Enable, Power Good, Soft Start
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 12-TSSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package 12-MSOP-EP
Base Product Number LT3045
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 800458-LT3045EMSE#TRPBF
Ultra Librarian 3D Model Ultra Librarian LT3045EMSE#TRPBF CAD Model

Description

Product Overview: LT3045EMSE#TRPBF by Analog Devices Inc.

The LT3045EMSE#TRPBF is a high-performance, low-noise, low-dropout voltage linear regulator from Analog Devices Inc., a leader in the field of high-performance analog technology. This regulator is designed to deliver up to 500mA of continuous output current with a dropout voltage of only 300mV at full load, making it an ideal solution for precision, high-power supply applications.

Featuring an ultra-low noise output of just 2uV RMS and a very high power supply rejection ratio (PSRR) of 76dB at 1kHz, the LT3045EMSE#TRPBF is perfect for sensitive RF or audio applications where a clean and stable power supply is critical. The device operates over a wide input voltage range from 1.8V to 20V, which allows for flexible usage in various circuit designs and applications.

The LT3045EMSE#TRPBF is housed in a compact MSOP-12 package, which is designed for space-saving in dense circuit boards while still providing excellent thermal performance. The regulator also includes internal protection features such as over-current protection, reverse battery protection, and thermal limiting, which contribute to the long-term reliability and stability of the end application.

One of the key features of this product is its programmable output voltage, which can be set from 0V to 15V with a single resistor. In addition, the LT3045EMSE#TRPBF offers a fast transient response, which is particularly important for applications where the load conditions change rapidly, such as digital processors and FPGA power supplies.

Overall, the LT3045EMSE#TRPBF from Analog Devices Inc. stands out for its exceptional performance in noise-sensitive applications, offering designers a high degree of precision and flexibility. Whether used in test equipment, medical devices, audio equipment, or high-end electronics, this linear regulator ensures a clean, stable, and reliable power supply, contributing to the optimal performance of the overall system.

For more detailed specifications and application guidance, designers are encouraged to consult the full datasheet and technical documentation provided by Analog Devices Inc.
