Same model may have multiple batches, images only for reference.

OP4177ARZ-REEL

Name: OP4177ARZ-REEL
Brand: Analog Devices Inc.
SKU: 650552
Availability: InStock
Rating: 5 (995 reviews)

Part No	OP4177ARZ-REEL
Manufacturer	Analog Devices Inc.
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP GP 4 CIRCUIT 14SOIC / General Purpose Amplifier 4 Circuit 14-SOIC
Datasheet	OP4177ARZ-REEL Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $1.8819

Quantity

Unit Price

Ext. Price

19+

$2.6850

$51.015

46+

$2.2030

$101.338

71+

$2.1340

$151.514

97+

$2.0660

$200.402

126+

$1.9970

$251.622

168+

$1.7900

$300.720

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 141,280 pieces

MOQ: 19 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Category	Integrated Circuits (ICs) - Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Mfr	Analog Devices Inc.
Package	Tape & Reel
Product Status	Active
Amplifier Type	General Purpose
Number of Circuits	4
Slew Rate	0.7V/µs
Gain Bandwidth Product	1.3 MHz
Current - Input Bias	500 pA
Voltage - Input Offset	15 µV
Current - Supply	400µA (x4 Channels)
Current - Output / Channel	10 mA
Voltage - Supply Span (Min)	5 V
Voltage - Supply Span (Max)	30 V
Temperature Range - Operating	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	14-SOIC (0.154", 3.90mm Width)
Supplier Device Package	14-SOIC
Base Product Number	OP4177
Standard Package	2,500 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.33.0001
Win Source Part Number	650552-OP4177ARZ-REEL
Fake Threat In the Open Market	34pct.

Description

Product Overview: OP4177ARZ-REEL by Analog Devices Inc.

The OP4177ARZ-REEL is a high-performance operational amplifier (op-amp) from the reputable Analog Devices Inc., designed for a wide array of applications requiring precision and stability. Packaged in a convenient reel form, it is ideal for automated manufacturing processes, ensuring efficiency and consistency in production.

Key Features

Precision Performance: The OP4177ARZ-REEL is characterized by its low offset voltage and drift, making it suitable for applications that demand high accuracy over time and temperature variations.
Quad Operational Amplifier: This device integrates four independent op-amps in a single package, providing excellent space-saving benefits for complex circuits.
Low Noise: With its low noise specifications, the OP4177ARZ-REEL is an excellent choice for audio and instrumentation applications where signal integrity is paramount.
Wide Supply Range: It operates with a wide supply voltage range, accommodating various power supply configurations and making it versatile for multiple applications.
Rail-to-Rail Output: The op-amp features rail-to-rail output, which allows the output signal to swing close to the supply rails, maximizing the dynamic range in battery-powered and single-supply systems.

Applications

The OP4177ARZ-REEL is designed to cater to a broad spectrum of applications, including but not limited to:

Precision instrumentation
Data acquisition systems
Process controls
Automotive controls
Professional audio equipment
Active filters and buffers

Technical Specifications

Some of the notable technical specifications of the OP4177ARZ-REEL include:

Supply Voltage: ±2.5 V to ±18 V
Input Offset Voltage: 75 µV max
Offset Voltage Drift: 1 µV/°C max
Low Noise: 8 nV/√Hz @ 1 kHz
Operating Temperature Range: -40°C to +125°C
Package: SOIC-14

The OP4177ARZ-REEL from Analog Devices Inc. is a testament to the company's commitment to providing high-quality components that meet the rigorous demands of modern electronic systems. Its combination of precision, low noise, and integration makes it a go-to choice for designers and engineers looking for reliable and efficient op-amp solutions.
