REF195ESZ

Part No REF195ESZ
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 5V 8SOIC / V-Ref Precision 5V 30mA 8-Pin SOIC N Tube
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 5V
Output Current 30mA
Tolerance ±0.04%
Temperature Coefficient 5ppm/°C
Noise - 0.1Hz to 10Hz 50μVp-p
Voltage - Input 5.1 V to 15 V
Operating Supply Current 45μA
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 042309-REF195ESZ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name REF195
Introduction Date January 01, 1996
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian REF195ESZ CAD Model

Description

The REF195ESZ from Analog Devices Inc. is a precision voltage reference that provides a stable output voltage with low noise and low drift. This component is part of a family of industry-standard voltage references that are widely used in various applications requiring a stable voltage source for accurate analog-to-digital conversion, power supply control, and voltage regulation.

Key Features

  • Output Voltage: The REF195ESZ offers a fixed output voltage of 5V, which is ideal for 5V systems and can be used to provide a stable reference for ADCs and DACs.
  • High Accuracy: With an initial accuracy of ±0.15%, this voltage reference ensures precise voltage regulation for sensitive electronic circuits.
  • Low Temperature Coefficient: It has a low temperature coefficient (TC) of 10ppm/°C max, which means the output voltage remains stable across a wide temperature range.
  • Low Dropout Voltage: The device operates with a low dropout voltage, which enhances its efficiency and allows it to function correctly even under low input voltage conditions.
  • Low Noise: It exhibits low noise characteristics, making it suitable for high-performance applications where noise can significantly impact system performance.
  • Long-Term Stability: The REF195ESZ demonstrates excellent long-term stability, ensuring consistent performance over the life of the product.

Applications

The REF195ESZ is versatile and can be used in a wide array of applications, including:

  • Data acquisition systems
  • Instrumentation
  • Medical devices
  • Industrial control systems
  • Precision power supplies
  • Battery-powered devices

Package and Quality

The REF195ESZ comes in an 8-lead SOIC package, which is compact and suitable for surface-mount technology (SMT), making it easy to integrate into various electronic systems. Analog Devices Inc. is known for its commitment to quality, and this product is no exception, meeting high standards to ensure reliability and performance.

For engineers and designers looking for a reliable voltage reference, the REF195ESZ from Analog Devices Inc. offers the precision and stability needed for critical applications.
