XC0900P-10S Real Image
Same model may have multiple batches, images only for reference.

XC0900P-10S

Part No XC0900P-10S
Manufacturer Anaren
Catalog RF Directional Coupler
Description COUPLER HYBRID 800-1000MHZ 10DB
Datasheet
XC0900P-10S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Anaren
Packaging Reel - TR
Status Active
Coupler Type Standard
Frequency 800MHz to 1GHz
Coupling Factor 10dB
Applications General Purpose
Insertion Loss 0.38dB
Maximum Power Dissipation 55W
Win Source Part Number 214032-XC0900P-10S
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian XC0900P-10S CAD Model

Description

The Anaren 214032-XC0900P-10S coupler is a standard type coupler designed for general-purpose applications.

  • Frequency Range: 800MHz to 1GHz
  • Coupling Factor: 10dB
  • Insertion Loss: 0.38dB
  • Maximum Power Dissipation: 55W
  • Packaging: Reel
  • Quantity: 2k pcs
  • Supply and Demand Status: Limited
