PTH12050YAD Emerson Network Power
Same model may have multiple batches, images only for reference.

PTH12050YAD

Part No PTH12050YAD
Manufacturer Artesyn Embedded Technologies
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 0.55-1.8V 10.8W
Datasheet
PTH12050YAD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Artesyn Embedded Technologies
Series PTHxx050Y (10.8W)
Package Tray
Product Status Obsolete
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 0.55 ~ 1.8V
Current - Output (Max) 6A
Power (Watts) 10.8 W
Applications ITE (Commercial)
Features Remote On/Off, OCP, UVLO
Temperature Range - Operating -40°C ~ 85°C
Efficiency 85%
Mounting Type Through Hole
Package / Case 6-DIP Module
Size / Dimension 0.87" L x 0.50" W x 0.34" H (22.1mm x 12.6mm x 8.5mm)
Standard Package 56 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 657954-PTH12050YAD
Ultra Librarian 3D Model Ultra Librarian PTH12050YAD CAD Model

Description

The 657954-PTH12050YAD is a DC-DC converter module from the PTHxx050Y series. 657954-PTH12050YAD is manufactured by Artesyn Embedded Technologies.

  • Series: PTHxx050Y
  • Type: Non-isolated point-of-load (PoL)
  • Power Rating: 10.8W
  • Features: Remote on/off, overcurrent protection (OCP), and undervoltage lockout (UVLO)
  • Package Form Factor: Tray
  • Dimensions: 0.87" L x 0.50" W x 0.34" H (22.1mm x 12.6mm x 8.5mm)
  • Application: ITE (Commercial)
  • Output Count: Single
  • Maximum Current Rating: 6A
  • Input Voltage: 10.8V to 13.2V
  • Output Voltage: Adjustable from 0.55V to 1.8V
  • Efficiency: 85%
  • Operating Temperature: -40°C to 85°C
  • Status: Obsolete
  • MSL: 3 (168 Hours)
