AT91SAM7X256C-AU Atmel AT91SAM7X256C-AU Real Image AT91SAM7X256C-AU real image2166 AT91SAM7X256C-AU Real Image1 AT91SAM7X256C-AU Real Image2 AT91SAM7X256C-AU Real Image3 AT91SAM7X256C-AU Real Image4
AT91SAM7X256C-AU Atmel AT91SAM7X256C-AU Real Image AT91SAM7X256C-AU real image2166 AT91SAM7X256C-AU Real Image1 AT91SAM7X256C-AU Real Image2 AT91SAM7X256C-AU Real Image3 AT91SAM7X256C-AU Real Image4
Same model may have multiple batches, images only for reference.

AT91SAM7X256C-AU

Part No AT91SAM7X256C-AU
Manufacturer Atmel
Catalog Embedded - Microcontrollers
Description MCU 16-bit/32-bit ARM7TDMI RISC 256KB Flash 1.85V/3.3V 100-Pin LQFP Tray / IC MCU 32BIT 256KB FLASH 100LQFP
Datasheet
AT91SAM7X256C-AU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Core Processor ARM7
Part Core Size 16/32-Bit
Speed(Frequency) 55MHz
Number of I/O 62
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Data RAM Size 64K x 8
Supply Voltage - Operating 1.65 V to 1.95 V
Data Converters A/D 8x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 100-LQFP (14x14)
Win Source Part Number 010355-AT91SAM7X256C-AU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name AT91SAM7X256
Introduction Date May 02, 1997
ECCN 3A991.a.2
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian AT91SAM7X256C-AU CAD Model

Description

Description

The AT91SAM7X256C-AU provides reliable computing power for embedded systems. Highly integrated with 256KB of Flash and 64KB of SRAM, this microcontroller supports demanding applications needing network connectivity.

Applications

  • Telecommunications
  • Network Protocol Converters
  • Instrumentation
  • Smart Energy Devices

Features and Benefits

  • Ethernet-Ready: Embedded Ethernet MAC supports advanced networking solutions.
  • Performance-Driven Core: 48 MHz ARM7TDMI? processor for complex tasks.
  • On-Chip Memory: Ample 256KB Flash and 64KB SRAM for multitasking applications.
  • Low Power Consumption: Ideal for power-sensitive applications.

Additional Details

  • Comprehensive Support: Supported by an extensive set of development tools.
  • 100-pin QFP Package: Streamlined for easy soldering and assembly.
