SV13CA472JAR Real Image
Same model may have multiple batches, images only for reference.

SV13CA472JAR

Part No SV13CA472JAR
Manufacturer AVX Corp/Kyocera Corp
Catalog Ceramic Capacitors
Datasheet
SV13CA472JAR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Ceramic Capacitors
Mfr KYOCERA AVX
Series SV
Package Bulk
Capacitance 4700 pF
Tolerance ±5%
Voltage - Rated 630V
Temperature Coefficient C0G, NP0
Temperature Range - Operating -55°C ~ 125°C
Features High Voltage
Applications General Purpose
Mounting Type Through Hole
Package / Case Radial
Dimension 0.300" L x 0.200" W (7.62mm x 5.08mm)
Height - Seated (Max) 0.360" (9.14mm)
Lead Spacing 0.200" (5.08mm)
Lead Style Straight
Other Names 478-5387
Standard Package 300
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.24.0060
Win Source Part Number 1302916-SV13CA472JAR
Ultra Librarian 3D Model Ultra Librarian SV13CA472JAR CAD Model

Description

The KYOCERA AVX 1302916-SV13CA472JAR is a ceramic capacitor with a capacitance of 4700 pF and a voltage rating of 630V.

  • Capacitance: 4700 pF
  • Voltage Rating: 630V
  • Application: General-Purpose
  • Tolerance: ±5%
  • Temperature Coefficient: C0G, NP0
  • Series: SV
  • Feature: High Voltage
  • Packaging: Bulk
  • Lead Spacing: 0.200" (5.08mm)
  • Package/Case: Radial
  • Height (Seated): 0.360" (9.14mm)
  • Temperature Range: -55°C ~ 125°C
  • Application: General Purpose
