The 4606X-101-472LF is a thick film isolated resistor network from Bourns, designed for applications requiring multiple, independent resistors in a single package. This device provides a compact and efficient solution for pull-up, pull-down, current limiting, and voltage divider circuits.

Applications:

• Digital Logic Circuits: Used for pull-up and pull-down resistor applications.
• LED Current Limiting: Used to limit current in LED circuits.
• Voltage Dividers: Used in voltage divider networks for sensor interfaces.
• Op-Amp Circuits: Used as feedback resistors in operational amplifier circuits.
• Interface Circuits: Used for signal termination.

Features:

• Isolated Resistors: Each resistor is electrically isolated from the others within the package.
• Thick Film Construction: Provides stable and reliable performance.
• Compact Design: Saves valuable board space.
• RoHS Compliant: Compliant with the RoHS directive for environmental protection.
• Wide Resistance Range: Available in a variety of resistance values.

Benefits:

• Reduced Board Space: Minimizes the footprint on the PCB, enabling smaller designs.
• Lower Component Count: Simplifies assembly and reduces BOM (Bill of Materials) complexity.
• Improved Reliability: Offers consistent and reliable performance compared to discrete resistors.
• Simplified Inventory Management: Reduces the number of different resistor values needed in inventory.
• Enhanced Circuit Performance: Provides closely matched resistor characteristics for improved circuit accuracy.

Additional Details:

The 4606X-101-472LF features a resistance value of 4.7 kOhms per resistor. It contains 6 isolated resistors. The power rating per resistor is typically around 0.25W, and the operating temperature range is typically from -55°C to +125°C. The resistance tolerance is often around ±2%, providing good precision. The package is a SIP (Single In-line Package) which facilitates easy insertion into PCBs. The “LF” suffix indicates that the component is lead-free, making it compliant with environmental regulations.
