Bourns Inc. presents the SDE0805A series of inductors, coils, and chokes, which are fixed inductors with a drum core and wirewound type.

• Core Type: Drum Core
• Inductor Type: Wirewound
• Shielding: Unshielded
• Inductance: 15 µH
• Tolerance: ±20%
• Package: Tape and Reel
• Standard Package: 1,000 pieces
• Height: 0.217 inches (5.50 mm) Max
• Mounting: SMD (SMT)
• Rating: AEC-Q200
• Material: Ferrite
• Frequency Self-Resonant: 22.5MHz
• Package/Case: Nonstandard
• DC Resistance (DCR): 90mOhm Max
• Temperature Range: -40°C to 125°C
• Dimensions: 0.307 inches L x 0.276 inches W (7.80mm x 7.00mm)
• Current Rating (Amps): 2.5A
• Inductance Frequency-Test: 1 MHz
• MSL Level: 1 (Unlimited)
