SDR0503-562JL

Name: SDR0503-562JL
Brand: Bourns Inc.
SKU: 1274817
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SDR0503-562JL
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SDR0503-562JL Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SDR0503
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	5.6 mH
Tolerance	±5%
Current Rating (Amps)	38 mA
Current - Saturation (Isat)	50mA
Shielding	Unshielded
DC Resistance (DCR)	72Ohm Max
Q @ Freq	40 @ 252kHz
Frequency - Self Resonant	1MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.197" L x 0.189" W (5.00mm x 4.80mm)
Height - Seated (Max)	0.130" (3.30mm)
Base Product Number	SDR0503
Other Names	SDR0503-562JLTR,SDR0503-562JL,SDR0503-562JLDKR,SDR0503-562JLCT
Standard Package	500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1274817-SDR0503-562JL
Ultra Librarian 3D Model	Ultra Librarian SDR0503-562JL CAD Model

Alternative Products

Description

The Bourns Inc. SDR0503 series fixed inductor is a wirewound component with a drum core and ferrite material.

Inductance: 5.6 mH
Tolerance: ±5%
Shielding: Shielded
Standard Packages: 500
Mounting Type: SMD (SMT)
Height: 0.130" (3.30mm)
Package/Case: Nonstandard
Dimension: 0.197" L x 0.189" W (5.00mm x 4.80mm)
Operating Temperature Range: -40°C ~ 125°C
ECCN: EAR99
Current Rating: 38 mA
