Same model may have multiple batches, images only for reference.
SRP0615-4R7K Real Image
Same model may have multiple batches, images only for reference.

SRP0615-4R7K

Part No SRP0615-4R7K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0615
Package Tape & Reel
Material - Core Metal
Inductance 4.7 µH
Tolerance ±10%
Current Rating (Amps) 4.3 A
Current - Saturation (Isat) 6A
Shielding Shielded
DC Resistance (DCR) 62mOhm Max
Q @ Freq 33 @ 7.96MHz
Frequency - Self Resonant 16MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.280" L x 0.264" W (7.10mm x 6.70mm)
Height - Seated (Max) 0.059" (1.50mm)
Other Names 118-SRP0615-4R7KTR,118-SRP0615-4R7KCT,118-SRP0615-4R7KDKR
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274169-SRP0615-4R7K
Ultra Librarian 3D Model Ultra Librarian SRP0615-4R7K CAD Model

Description

The Bourns Inc. SRP0615-4R7K is a fixed inductor with a tolerance of ±10%.

  • Current Rating: 4.3A
  • Saturation Current: 6A
  • Height Seated (Max): 0.059" (1.50mm)
  • DC Resistance (DCR): 62mOhm Max
  • Win Source Part Number: 1274169-SRP0615-4R7K
