Same model may have multiple batches, images only for reference.

SRP1250-6R0M

Name: SRP1250-6R0M
Brand: Bourns Inc.
SKU: 1274054
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SRP1250-6R0M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP1250-6R0M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP1250
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Iron
Inductance	6 µH
Tolerance	±20%
Current Rating (Amps)	9.5 A
Current - Saturation (Isat)	14A
Shielding	Shielded
DC Resistance (DCR)	10mOhm Max
Temperature Range - Operating	-55°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max)	0.232" (5.90mm)
Base Product Number	SRP1250
Other Names	SRP1250-6R0MDKR,SRP1250-6R0MCT,SRP1250-6R0M,SRP1250-6R0MTR,SRP12506R0M
Standard Package	500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1274054-SRP1250-6R0M
Ultra Librarian 3D Model	Ultra Librarian SRP1250-6R0M CAD Model

Alternative Products

Description

The SRP1250-6R0M is a shielded drum core inductor from Bourns Inc.

Type: Wirewound
Inductance: 6 µH
Tolerance: ±20%
Rated Current: 9.5 A
DC Resistance (DCR): 10 mOhm max
Height: 0.232" (5.90 mm)
Dimension: 0.547" L x 0.531" W (13.90 mm x 13.50 mm)
Frequency Self-Resonant: Not Specified
Q @ Freq: Not Specified
Package: Nonstandard
Standard Package: 500
Applications: Power Supplies, DC-DC Converters, and EMI Filtering
