SRP3020C-R47M Real Image
Same model may have multiple batches, images only for reference.

SRP3020C-R47M

Part No SRP3020C-R47M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP3020C-R47M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3020C
Package Tape & Reel
Material - Core Metal
Inductance 470 nH
Tolerance ±20%
Current Rating (Amps) 6 A
Current - Saturation (Isat) 7A
Shielding Shielded
DC Resistance (DCR) 23mOhm Max
Q @ Freq 10 @ 100kHz
Frequency - Self Resonant 83MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP3020C-R47MTR,118-SRP3020C-R47MDKR,118-SRP3020C-R47MCT
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273957-SRP3020C-R47M
Ultra Librarian 3D Model Ultra Librarian SRP3020C-R47M CAD Model

Description

The SRP3020C-R47M is a shielded fixed inductor from Bourns Inc.

  • Inductance: 470 nH
  • Tolerance: ±20%
  • Packaging: Tape and Reel
  • Height: 0.079" (2.00mm)
  • Series: SRP3020C
  • Core Material: Metal
  • Q @ Freq: 10 @ 100kHz
  • Frequency - Self Resonant: 83MHz
  • Package/Case: Non-Standard
  • Dimension: 0.138" L x 0.126" W (3.50mm x 3.20mm)
  • Temperature Range: -40°C to 125°C
  • ECCN: EAR99 compliant
  • REACH: Unaffected
