Same model may have multiple batches, images only for reference.

SRP4020-R22M

Name: SRP4020-R22M
Brand: Bourns Inc.
SKU: 1273924
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SRP4020-R22M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP4020
Package	Tape & Reel
Product Status	Obsolete
Type	Molded
Material - Core	Iron
Inductance	220 nH
Tolerance	±20%
Current Rating (Amps)	11.5 A
Current - Saturation (Isat)	11.5A
Shielding	Shielded
DC Resistance (DCR)	7mOhm Max
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.189" L x 0.157" W (4.80mm x 4.00mm)
Height - Seated (Max)	0.079" (2.00mm)
Base Product Number	SRP4020
Other Names	SRP4020-R22MDKR,SRP4020R22M,SRP4020-R22MTR,SRP4020-R22MCT
Standard Package	2,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273924-SRP4020-R22M
Ultra Librarian 3D Model	Ultra Librarian SRP4020-R22M CAD Model

Alternative Products

Description

The Bourns Inc. SRP4020 series fixed inductor is a high-quality component designed for use in electronic circuits.

Type: Molded
Shielding: Shielded
Inductance: 220 nH
Tolerance: ±20%
Height Seated (max): 0.079" (2.00mm)
Package: tape & reel
DC Resistance (DCR): 7mOhm Max
REACH: unaffected
ECCN: EAR99
Package Quantity: 2,000
