SRP5030TA-3R3M Real Image
Same model may have multiple batches, images only for reference.

SRP5030TA-3R3M

Part No SRP5030TA-3R3M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP5030TA-3R3M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5030TA
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Carbonyl Powder
Inductance 3.3 µH
Tolerance ±20%
Current Rating (Amps) 5 A
Current - Saturation (Isat) 8A
Shielding Shielded
DC Resistance (DCR) 38mOhm Max
Q @ Freq 15 @ 100kHz
Frequency - Self Resonant 30MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 150°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.118" (3.00mm)
Base Product Number SRP5030TA
Other Names SRP5030TA-3R3MDKR,SRP5030TA-3R3MCT,SRP5030TA-3R3MTR
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273850-SRP5030TA-3R3M
Ultra Librarian 3D Model Ultra Librarian SRP5030TA-3R3M CAD Model

Description

The SRP5030TA-3R3M is a drum core wirewound inductor from Bourns Inc.

  • Shielded: Yes
  • Inductance: 3.3 µH
  • Tolerance: ±20%
  • DC Resistance (DCR): 38 mOhm max
  • Current Rating: 5 A
  • Q @ Freq: 15 @ 100 kHz
  • Frequency of Self-Resonant: 30 MHz
  • AEC-Q200 Rated: Yes
  • Package: Nonstandard
  • Mounting: SMD (SMT) technology
  • Temperature Range: -40°C to 150°C
