SMAJ24CA Real Image SMAJ24CA real image5573
Same model may have multiple batches, images only for reference.
SMAJ24CA Real Image SMAJ24CA real image5573
SMAJ24CA Real Image SMAJ24CA real image5573
Same model may have multiple batches, images only for reference.

SMAJ24CA

Part No SMAJ24CA
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 24VWM 38.9VC DO214AC
Datasheet
SMAJ24CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 24V
Minimum Breakdown Voltage 26.7V
Max Clamping Voltage 38.9V
Peak Pulse Current(Ippm) 10.3A
Power Dissipation - Pd 400W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMA (DO-214AC)
Win Source Part Number 095637-SMAJ24CA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Industrial
Package Tape & Reel (TR);Cut Tape (CT)
Product Status Active
Voltage - Reverse Standoff (Typ) 24V (Max)
Voltage - Breakdown (Min) 28.1V (Typ)
Voltage - Clamping (Max) @ Ipp 38.9V
Current - Peak Pulse (10/1000µs) 10.3A
Power - Peak Pulse 400W
Power Line Protection No
Operating Temperature -65°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC
Voltage - Reverse Standoff (Typ) 24V
Voltage - Breakdown (Min) 26.7V
Operating Temperature -55°C ~ 150°C (TJ)
Supplier Device Package DO-214AC (SMA)
Ultra Librarian 3D Model Ultra Librarian SMAJ24CA CAD Model

Description

The Bourns SMAJ24CA is a surface mount Zener diode designed for general purpose applications.

  • Stand-off Voltage: 24V
  • Minimum Breakdown Voltage: 26.7V
  • Peak Pulse Current: 10.3A
  • Power Dissipation: 400W
  • Supply and Demand: Balanced
  • Applications: Computers and computer peripherals, communications and networking, consumer electronics, and industrial applications
