SMAJ36CA Real Image SMAJ36CA real image5575 SMAJ36CA Real Image1 SMAJ36CA Real Image2
Same model may have multiple batches, images only for reference.
SMAJ36CA Real Image SMAJ36CA real image5575 SMAJ36CA Real Image1 SMAJ36CA Real Image2
SMAJ36CA Real Image SMAJ36CA real image5575 SMAJ36CA Real Image1 SMAJ36CA Real Image2
Same model may have multiple batches, images only for reference.

SMAJ36CA

Part No SMAJ36CA
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 36VWM 58.1VC DO214AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Standard Package 1
Category Circuit Protection
Family TVS - Diodes
Series SMAJ
Packaging Reel
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 36V
Voltage - Breakdown (Min) 40V
Voltage - Clamping (Max) @ Ipp 58.1V
Current - Peak Pulse (10/1000µs) 6.9A
Power - Peak Pulse 400W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AC SMA
Manufacturer Device Package SMA (DO-214AC)
Catalog SMAJ Series
Win Source Part Number 084248-SMAJ36CA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Industrial
Package Tape & Reel (TR);Cut Tape (CT)
Product Status Active
Operating Temperature -65°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
Ultra Librarian 3D Model Ultra Librarian SMAJ36CA CAD Model

Description

The Bourns Inc. SMAJ36CA is a Zener diode designed for general-purpose applications in computers and computer peripherals, communications and networking, consumer electronics, and industrial devices.

  • Type: TVS diode
  • Series: SMAJ
  • Channel: Bidirectional
  • Reverse Standoff Voltage: 36V
  • Voltage Breakdown: 40V
  • Voltage Clamping @ Ipp: 58.1V
  • Peak Pulse Power: 400W
  • Current Peak Pulse: 6.9A
  • Package: DO-214AC SMA
  • Operating Temperature: -55°C to 150°C
  • Packaging: Reel
  • Popularity: High
  • Usage: Common
