SRF1260-680M

Part No SRF1260-680M
Manufacturer Bourns Inc.
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 68UH SMD / Shielded 2 Coil Inductor Array 272 µH Inductance - Connected in Series 68 µH Inductance - Connected in Parallel 117mOhm Max DC Resistance (DCR) - Parallel 2.22 A Nonstandard
Datasheet
SRF1260-680M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Arrays, Signal Transformers
Mfr Bourns Inc.
Series SRF1260
Package Tape & Reel
Number of Coils 2
Inductance - Connected In Parallel 68 µH
Inductance - Connected In Series 272 µH
Tolerance ±20%
Current Rating - Parallel 2.22 A
Current Rating - Series 1.11 A
Current Saturation - Parallel 2.7 A
Current Saturation - Series 1.35 A
DC Resistance (DCR) - Parallel 117mOhm Max
DC Resistance (DCR) - Series 444mOhm Max
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.244" (6.20mm)
Base Product Number SRF1260
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Other Names SRF1260680M,SRF1260-680MTR,SRF1260-680MDKR,SRF1260-680MCT
Standard Package 400
Win Source Part Number 1095929-SRF1260-680M
Ultra Librarian 3D Model Ultra Librarian SRF1260-680M CAD Model

Description

The Bourns Inc. 1095929-SRF1260-680M is a surface mount inductor with a shielded package.

  • Mounting: Surface mount
  • Package: Tape and reel
  • Case: Nonstandard
  • Tolerance: ±20%
  • Height: 0.244 inches (6.20mm)
  • Coils: 2
  • Inductance (Series): 272 µH
  • Inductance (Parallel): 68 µH
  • Current Rating (Series): 1.11A
  • Current Rating (Parallel): 2.22A
  • Current Saturation (Series): 1.35A
  • Current Saturation (Parallel): 2.7A
  • DC Resistance (DCR) (Series): 444mOhm
  • DC Resistance (DCR) (Parallel): 117mOhm
  • Operating Temperature: -40°C to 125°C
