DRQ127-221-R Real Image
Same model may have multiple batches, images only for reference.

DRQ127-221-R

Part No DRQ127-221-R
Manufacturer Cooper Bussmann, Inc.
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 221.5UH SMD / Dual winding, high power density, shielded drum core power inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Eaton - Electronics Division
Packaging Reel
Number of Coils 2
Inductance - Connected In Parallel 221.5μH
Inductance - Connected In Series 886μH
Tolerance ±20%
Current Rating - Parallel 1.29A
Current Rating - Series 645mA
Current Saturation - Parallel 2.43A
Current Saturation - Series 1.22A
DC Resistance (DCR) - Parallel 376mOhm
DC Resistance (DCR) - Series 1.5Ohm
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.315" (8.00mm)
Manufacturer Pack Quantity 350
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810704-DRQ127-221-R
Ultra Librarian 3D Model Ultra Librarian DRQ127-221-R CAD Model

Description

The DRQ127-221-R is an electronic component from Eaton - Electronics Division.

  • Shielding: Yes
  • Inductance (Series): 886μH
  • Inductance (Parallel): 221.5μH
  • Tolerance: ±20%
  • Current Rating (Parallel): 1.29A
  • Current Rating (Series): 645mA
  • Current Saturation (Parallel): 2.43A
  • Current Saturation (Series): 1.22A
  • DC Resistance (DCR) (Parallel): 376mOhm
  • DC Resistance (DCR) (Series): 1.5Ohm
  • Temperature Range: -40°C to 125°C
