ACPL-K43T-000E Real Image ACPL-K43T-000E real image17066
Same model may have multiple batches, images only for reference.
ACPL-K43T-000E Real Image ACPL-K43T-000E real image17066
ACPL-K43T-000E Real Image ACPL-K43T-000E real image17066
Same model may have multiple batches, images only for reference.

ACPL-K43T-000E

Part No ACPL-K43T-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Automotive R2CouplerTM Wide Operating Temperature | OPTOISOLATOR 5KV TRANSISTOR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 32% at 10mA
Current Transfer Ratio (Maximum) 100% at 10mA
Turn On / Turn Off Time 150ns, 500ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Current - Output / Channel 8mA
Voltage - Forward (Vf) 1.55V
Current - DC Forward (If) (Maximum) 20mA
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-SOIC (0.268", 6.81mm Width)
Supplier Device Package 8-SO
Manufacturer Pack Quantity 80
MSL Level 1 (Unlimited)
Win Source Part Number 1135391-ACPL-K43T-000E
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ACPL-K43T-000E CAD Model

Description

The Broadcom Limited 1135391-ACPL-K43T-000E is an Isolator with a current output of 8mA and voltage isolation of 5000Vrms.

  • Temperature Range: -40°C to 125°C.
  • Maximum Output Voltage: 20V.
  • Package: 8-SOIC (0.268", 6.81mm Width) package.
  • Supply and Demand Status: Limited.
  • Current Transfer Ratio: Minimum 32% @ 10mA and maximum 100% @ 10mA.
  • Turn On/Off Time: 150ns and 500ns respectively.
