HCPL-2430-000E Real Image HCPL-2430-000E Real Image1 HCPL-2430-000E Real Image2 HCPL-2430-000E Real Image3 HCPL-2430-000E Real Image4 HCPL-2430-000E Real Image5
Same model may have multiple batches, images only for reference.
HCPL-2430-000E Real Image HCPL-2430-000E Real Image1 HCPL-2430-000E Real Image2 HCPL-2430-000E Real Image3 HCPL-2430-000E Real Image4 HCPL-2430-000E Real Image5
HCPL-2430-000E Real Image HCPL-2430-000E Real Image1 HCPL-2430-000E Real Image2 HCPL-2430-000E Real Image3 HCPL-2430-000E Real Image4 HCPL-2430-000E Real Image5
Same model may have multiple batches, images only for reference.

HCPL-2430-000E

Part No HCPL-2430-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV 2CH PSH PULL 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 40MBd
Propagation Delay tpLH / tpHL (Max) 55ns, 55ns
Rise and Fall Time 20ns, 10ns
Forward Voltage 1.3V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 016860-HCPL-2430-000E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-2430-000E CAD Model

Description

The Broadcom Limited electronic component with Win Source Part Number 016860-HCPL-2430-000E is a medium popularity product with balanced supply and demand status.

  • Supply and Demand: Balanced
  • Data Rate: 40MBd
  • Channels: 2
  • Isolation Voltage: 3750Vrms
  • Package: 8-DIP
  • Mounting: Through Hole
  • Operating Temperature: -40°C to 85°C
  • Common Mode Transient Immunity: 1kV/μs
