HCPL-3120-500E Real Image HCPL-3120-500E Real Image
Same model may have multiple batches, images only for reference.
HCPL-3120-500E Real Image HCPL-3120-500E Real Image
HCPL-3120-500E Real Image HCPL-3120-500E Real Image
Same model may have multiple batches, images only for reference.

HCPL-3120-500E

Part No HCPL-3120-500E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 3.75KV GATE DRVR 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Approvals CSA, UR
Win Source Part Number 016869-HCPL-3120-500E
Family Name HCPL-3120
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Philippines, Singapore, Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL-3120-500E CAD Model

Description

The Broadcom Limited 016869-HCPL-3120-500E is an optical coupling technology electronic component with CSA and UR approval. The supply and demand status is sufficient. The estimated EOL date is 2023.

  • Manufacturer: Broadcom Limited
  • Technology: Optical Coupling
  • Application: Isolator
  • Case/Package: 8-DIP Gull Wing
  • Approvals: CSA, UR
