1N4685 TR Central Semiconductor Corp
Same model may have multiple batches, images only for reference.

1N4685 TR

Part No 1N4685 TR
Manufacturer Central Semiconductor Corp
Catalog Diodes - Zener - Single
Description DIODE ZENER 3.6V 500MW DO35
Datasheet
1N4685 TR Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 3.6V
Tolerance ±5%
Maximum Power Dissipation 500mW
Current - Reverse Leakage @ Vr 7.5μA @ 2V
Voltage - Forward (Vf) (Max) @ If 1.5V @ 100mA
Temperature Range - Operating -65°C to 200°C (TJ)
Mounting Through Hole
Case / Package DO-35
Win Source Part Number 1002127-1N4685 TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 1N4685 TR CAD Model

Description

The Central Semiconductor Corp 1N4685 TR is a zener diode with a voltage tolerance of ±5% and a forward voltage of 1.5V @ 100mA.

  • Voltage Tolerance: ±5%
  • Forward Voltage: 1.5V @ 100mA
  • Reverse Leakage Current: 7.5μA @ 2V
  • Zener Voltage: 3.6V
  • Maximum Power Dissipation: 500mW
  • Application: Discrete Semiconductor Products
  • Temperature Range: -65°C to 200°C
  • Package: DO-35
