PDZ12B,115 Real Image PDZ12B,115 label picture
Same model may have multiple batches, images only for reference.
PDZ12B,115 Real Image PDZ12B,115 label picture
PDZ12B,115 Real Image PDZ12B,115 label picture
Same model may have multiple batches, images only for reference.

PDZ12B,115

Part No PDZ12B,115
Manufacturer Nexperia USA Inc.
Catalog Diodes - Zener - Single
Description DIODE ZENER 12V 400MW SOD323
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Nexperia USA Inc.
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 12 V
Tolerance ±2%
Power - Max 400 mW
Impedance (Max) (Zzt) 10 Ohms
Current - Reverse Leakage @ Vr 100 nA @ 9 V
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 100 mA
Temperature Range - Operating 150°C (TJ)
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Supplier Device Package SOD-323
Base Product Number PDZ12
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 740694-PDZ12B,115
Ultra Librarian 3D Model Ultra Librarian PDZ12B,115 CAD Model

Description

The PDZ12B,115 is a Zener diode with a nominal Zener voltage of 12V.

  • Nominal Zener Voltage: 12V
  • Maximum Power Rating: 400mW
  • Forward Voltage: 1.1V @ 100mA
  • Reverse Leakage Current: 100nA @ 9V
  • Impedance: 10 Ohms
  • Mounting: Surface mountable
  • Package: SC-76, SOD-323
  • Package from Nexperia USA Inc.: 3,000 pieces
  • Product Status: Active
