Same model may have multiple batches, images only for reference.

EC7BW18-72S05

Name: EC7BW18-72S05
Brand: Cincon Electronics Co. LTD
SKU: 1348545
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	EC7BW18-72S05
Manufacturer	Cincon Electronics Co. LTD
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 20W / Isolated Module DC DC Converter 1 Output 5V 4A 8.5V - 160V Input
Datasheet	EC7BW18-72S05 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Cincon Electronics Co. LTD
Series	EC7BW18 (20W)
Package	Tube
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	8.5V
Voltage - Input (Max)	160V
Voltage - Output 1	5V
Current - Output (Max)	4A
Power (Watts)	20 W
Voltage - Isolation	3 kV
Applications	ITE (Commercial) , Railway
Features	Adjustable Output, Remote On/Off
Temperature Range - Operating	-40°C ~ 105°C (With Derating)
Efficiency	86%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Size / Dimension	2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
Control Features	Enable, Active High
Approval Agency	CB, CE, cURus
Standard Number	50155; 62368-1
Base Product Number	EC7BW
Standard Package	12
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1348545-EC7BW18-72S05
Ultra Librarian 3D Model	Ultra Librarian EC7BW18-72S05 CAD Model

Alternative Products

Description

The Cincon Electronics Co. LTD 1348545-EC7BW18-72S05 is an isolated module DC-DC converter that belongs to the Power Supplies-Board Mount-DC DC Converters category.

Package: Tube
Power: 20W
Voltage Isolation: 3kV
Output: One
Current Output: 4A
Input Voltage: 8.5V to 160V
