CS5534-BSZ Cirrus Logic Inc. CS5534-BSZ real image
Same model may have multiple batches, images only for reference.
CS5534-BSZ Cirrus Logic Inc. CS5534-BSZ real image
CS5534-BSZ Cirrus Logic Inc. CS5534-BSZ real image
Same model may have multiple batches, images only for reference.

CS5534-BSZ

Part No CS5534-BSZ
Manufacturer Cirrus Logic Inc.
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 24BIT SIGMA-DELTA 24SSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Data Acquisition - Analog to Digital Converters (ADC)
Mfr Cirrus Logic Inc.
Package Tube
Product Status Active
Number of Bits 24
Sampling Rate (Per Second) 3.84k
Number of Inputs 4
Input Type Differential
Data Interface SPI
Configuration MUX-PGA-ADC
Number of A/D Converters 1
Architecture Sigma-Delta
Reference Type External
Voltage - Supply, Analog ±3V, 0V ~ 5V
Voltage - Supply, Digital 3V ~ 5V
Features PGA, Selectable Address
Temperature Range - Operating -40°C ~ 85°C
Package / Case 24-SSOP (0.209", 5.30mm Width)
Supplier Device Package 24-SSOP
Mounting Type Surface Mount
Base Product Number CS5534
Standard Package 59 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 580728-CS5534-BSZ
Ultra Librarian 3D Model Ultra Librarian CS5534-BSZ CAD Model

Description

The CS5534-BSZ is an analog to digital converter (ADC) designed for data acquisition.

  • Manufacturer: Cirrus Logic Inc.
  • Package: Tube
  • Standard Package: 59 pieces
  • Features: Programmable gain amplifier (PGA) and selectable address options
  • Inputs: 4 differential inputs
  • Architecture: Sigma-delta
  • Resolution: 24 bits
  • Sampling Rate: 3.84k samples per second
  • Data Interface: SPI
  • Reference Voltage: External
  • Voltage Supply (Analog): ±3V to 0V ~ 5V
  • Voltage Supply (Digital): 3V ~ 5V
  • Mounting Type: Surface mountable
  • Package: 24-SSOP
  • Operating Temperature: -40°C to 85°C
  • ECCN: EAR99
  • REACH Status: Unaffected
  • HTSUS Code: 8542.39.0001
  • Status: Active
  • Suitable for: Data acquisition applications
