The CL-165HR is a red LED manufactured by Citizen. It is a discrete LED indicator designed for a variety of applications where visual signaling or indication is needed. It's known for its brightness, reliability, and compact size.

Applications

• Panel indicators
• Status indicators
• Backlighting
• Consumer electronics
• Automotive lighting

Features

• Color: Red
• High brightness output
• Compact size
• Long lifespan
• Low power consumption

Benefits

• Clear visual indication
• Energy efficient
• Durable and reliable
• Easy to integrate
• Space-saving design

Technical Specifications

The CL-165HR typically operates at a forward voltage of around 1.8V to 2.2V and a forward current of approximately 20mA. The luminous intensity usually ranges from 50mcd to 100mcd, depending on the specific drive conditions. The viewing angle is generally between 20 and 30 degrees, providing a focused beam of light. This LED is designed for through-hole mounting, making it easy to integrate into existing circuit boards. The operating temperature range is typically from -40°C to +85°C, ensuring reliable performance in a variety of environments.

The Citizen CL-165HR LED is designed to provide bright and reliable indication in various applications. Its low power consumption and long lifespan make it an energy-efficient choice for status indicators and backlighting. Its compact size allows for easy integration into space-constrained designs. The red color is highly visible, making it suitable for applications where clear visual signaling is essential. Its robust construction ensures reliable performance in a wide range of operating conditions.
